Small Rechargeable 3.7V Lithium Polymer battery 602535 500mah
Brand: Green Battery|Model: DTP 602535
Product Highlights
3.7V 500mAh rechargeable battery for remote control helicopter / toy aircraft
Key attributes
ModelDTP 602535
Capacity500mAh
Size6*25*35mm
Nominal Voltage3.7V
Battery TypeLithium Polymer Battery
ApplicationRemote Control Helicopter / Toy Aircraft, Toys, Power Tools, Home Appliances, Medical Equipment
WeightTypically 10g
Place of OriginGuangdong, China
Energy1.85Wh
Internal ImpedanceLess than 180 mΩ
Max. Charge Voltage4.2V
Discharge Cut-off2.75V
Max. Charge Current500mA
Max. Discharge Current500mA
Cycle Life500 cycles (≥80% capacity retention)
Customization options
›Customized logo(Min. order: 1000 pieces)
Customized packaging(Min. order: 1000 pieces)
Customized connector and wire(Min. order: 1000 pieces)
Minor customization(Min. order: 1000 pieces)
Drawing-based customization(Min. order: 1000 pieces)
Raw material identification and traceability(Min. order: 1000 pieces)
Finished product inspection(Min. order: 1000 pieces)
Supplier’s capabilities
Response Time≤24h
On-time delivery100%
Shipping: Fee and delivery date to be negotiated. Chat with Green Battery now for details.
Request QuoteProduct Description
Product Overview
602535 is a compact 3.7V 500mAh lithium polymer rechargeable battery, suitable for medical equipment, remote control helicopters, toy aircraft, toys, power tools and home appliances.
Product Details
- Discharge Rate: Lithium batteries have varying discharge rates. These batteries can handle a maximum discharge rate of 5.0C, which means they can deliver high power output in short bursts.
- Long Cycle Life: This battery maintains over 80% capacity even after 500 charge-discharge cycles at 0.5C, all at room temperature.
- Ultra-Low Self-Discharge: Batteries display varying self-discharge rates depending on their charge states. Specifically, self-discharge is notably higher at a 100% state of charge (SOC) in comparison to a 70% SOC.
- Wide Temperature Range: Lithium batteries function within a discharge temperature range of -20°C to 60°C. Custom low-temperature batteries are designed for various outdoor scenarios and can work in -40°C to 55°C.
Battery Specification
1. Mechanical Characteristics
| Cell | 602535 |
| PCM | Yes |
| NTC | No |
| Weight | Appr. 10g |
| Configuration | 1S1P |
| Dimension | 6*25*37mm (MAX) |
2. Electrical Specification
| Capacity | 500mAh |
| Nominal Voltage | 3.7V |
| Energy | 1.85Wh |
| Internal Impedance | Less than 180 mΩ |
| Max. Charge Voltage | 4.2V |
| Discharge Cut Off | 2.75V |
| Max. Charge Current | 500mA |
| Max. Discharge Current | 500mA |
| Standard Charge Current | 250mA |
| Standard Discharge Current | 250mA |
| Charge Temp. Range | 0℃ to 45℃ |
| Discharge Temp. Range | -20℃ to 60℃ |
| Storage Temp. Range | 1 year at -20℃ to +30℃; 3 months at -20℃ to +45℃; 1 month at -20℃ to +60℃ |
| Cycle Life | 100 cycles ≥92%; 300 cycles ≥88%; 500 cycles ≥80% |
3. Cell Protection
| Overcharge Detection | 4.28V ±25mV (1 to 1.6s delay, release 4.2V ±50mV) |
| Overdischarge Detection | 2.5V ±50mV (115 to 175ms delay, release 3.0V ±50mV) |
| Overcurrent Detection | 2.5A to 4.0A (9 to 15ms delay) |
| Short Protection | Yes |
